SAHX-120B Load Sensor

Introduction:Overload, illegal dumping, unauthorized using of vehicles, fuel theft, illegal operation have been growing problems with the fast development of truck logistics. At one time, the administ

  • Model: SAHX-120B

Introduction:

Overload, illegal dumping, unauthorized using of vehicles, fuel theft, illegal operation have been growing problems with the fast development of truck logistics. At one time, the administrators had been helpless and obviously traditional solutions such as truck scale are not ideal for its high cost, higherror and failure rate.Based on the issues above, Soway Tech Ltd designs and produces a brand new load sensor, SAHX series, which has a longer life-expectancy and higher accuracy. Users can use SAHX alone or achieve multiple measurements on vehicles by utilizing other Soway sensors, GPS platforms at the same time.


Features:

- Measurements of empty, full-loaded, overloaded or weight.

- Special design, mounted on vehicles, long life expectancy.

- Easy installation and calibration, equipped with mounting blocks.

- Protection IP67, vibration-resistant design (5G/40Hz)


Technology:

SAHX is based on the technology of angle measurement. Displacement of leaf spring of the vehicle always happens when the weight changes. SAHX measures the displacement of leaf springs, the load status and weight can be computed accordingly.


Application:

Overload monitoring: Setting an alarm when the vehicle is overloaded with monitoring the load status in real time.

Dump truck management: Transporting times can be monitored.

Garbage truck management: different issues like overloaded, road damage can be avoided by monitoring the status of overload.

Vehicles balance monitoring: With the installations of the SAHX on both sides, administrators can judge whether the vehicle is in balance to prevent accidents like overturn. Protect your vehicles: Overload is definitely a killer of different types of vehicles, identify this killer by installing SAHX and take good care of your vehicles!

Save your dollars: Unauthorized using of the vehicles can be found and prevented.

MetInfo enterprise content manager system | MetInfo CMS


Specification:


MetInfo enterprise content manager system | MetInfo CMS


Dimension:

MetInfo enterprise content manager system | MetInfo CMS

MetInfo enterprise content manager system | MetInfo CMS



Wiring Output (optional):

MetInfo enterprise content manager system | MetInfo CMS

MetInfo enterprise content manager system | MetInfo CMS

MetInfo enterprise content manager system | MetInfo CMS


Installation:


MetInfo enterprise content manager system | MetInfo CMS




* NOTE :

1、The red arrow is the recommended installation point.

2、Please also select the position point fixed by the sensor mounting kit and L mounting kit.

3、Make sure the installation is welded or tightened through screws.

4、When the sensor is installed, the swing arm should be parallel and upward. A certain amount of activity space, at least     20CM.
